Deep CavityInspection System

GE Aerospace

Enhanced surface

inspection solution
Direct line of sight access with digital inspection technology. GE Aerospace’s Deep Cavity Inspection System allows a single operator to perform “Enhanced FPI Inspection” of deep cavity spools using a fully-automated system for highly repeatable, consistent results.
    GE Aerospace
    No borescope, handheld mirrors, light source or pin gauge needed
    Historically, spool surfaces have been FPI- and white-light inspected with mirrors or handheld borescopes. Our system eliminates the need for these tools while also providing a full inspection report with images.

    Engine spool compatibility:
    - GE90
    - GEnx
    - CFM LEAP
    - CF34-8
    - CF6-80C2 - Passport
    GE Aerospace
    Features
    • Pixel resolution up to 0.0005”
    • White light and UV Inspection capability
    • Automatic system validation:
      - Light intensity
      - Positioning
      - Optical Resolution

    System comparison

    Specification
    Typical Borescope System
    Deep Cavity Inspection System
    Automation level
    Manual
    Fully automatic
    Spool rotation
    Manual
    Motorized
    Spool rotation (360 degrees)
    No
    Yes
    Camera resolution
    ~1-2 Mpx
    18 Mpx
    System validation
    Manual
    Automated
    Tool tip change
    Manual
    Automated
    Defect documentation
    Manual
    Automated
    Measurement ability
    None
    Digital on image
    Autofocus
    Manual
    Digital
    Cycle time
    Long
    Short
    Inspection consistency and quality
    Human dependent
    Highly repeatable and consistent results
    Digital data
    None
    Full inspection report with images
    Typical borescope inspection view
    deep cavity inspection system view
